Distributed Antenna Systems – In Building
Modern construction materials, such as those used in LEED certified buildings, have the capability to block and otherwise degrade both internal and external wireless signals. These wireless signals use licensed radio frequencies and are blocked in much the same way as the sun’s radiating energy. Distributed antenna systems, otherwise known as DAS or “in-building radio signal amplification,” are designed to extend wireless coverage inside buildings and structures to allow radio and cellular communications devices to function. This is most important when it comes to the radio systems used by fire departments, police, and other first responders.
With the advent of the first Blackberry devices, wireless communication became ubiquitous. Now with the proliferation of Android and IOS devices being used throughout business and government, the requirement for stable and reliable cellular service from the various regulated carriers has become a de facto requirement for buildings. Today’s modern buildings use various materials to ensure energy efficiencies. These include various new types of insulation and coatings on exterior windows to block the sun’s heat. These same materials also inhibit the introduction of radio frequencies used by the major mobile carriers to provide service to their customer’s devices.
Section 915 of the 2009 International Building Code mandates needs assessment, testing, installation, and annual recertification of need/installation of public safety/emergency responder radio amplification systems in certain types of commercial and government buildings. The following are a few of the important requirements of this standard.
- All new buildings should have approved radio coverage for emergency responders within the building.
- Radio signal strength requirements must be met in 95% of all areas of each floor of the building, with particular emphasis on “means of egress” (stairwells, emergency exists, etc).
- All existing buildings should have radio coverage throughout the building and are required to retrofit the building with radio coverage if the existing wired system is not able to be repaired or is being replaced.
Aside from these guidelines, specific codes are set by various Authorities Having Jurisdiction (AHJ) and are set by state, county, and city government agencies.
Wycliffe Technologies, in conjunction with our various DAS partners, can provide a full turn-key assessment and proposal for your public safety DAS needs. For further information, please be sure to contact us today for an assessment of your requirements.
Cellular Signal Enhancement
Today’s modern buildings use various materials to ensure energy efficiencies. These include various new types of insulation and coatings on exterior windows to block the sun’s heat. These same materials also inhibit the introduction of radio frequencies used by the major mobile carriers to provide service to their customer’s devices.
Prior to the Blackberry, iPhone, and Android device explosion of recent years, mobile telephone users could tolerate service disruptions inside buildings. Now that email, web browsing, instant messaging, and other services are tied to the use of the mobile device, these outages are disrupting and are no longer tolerable.
So how does the modern building manager, owner, or tenant rectify these two requirements of energy efficiency and ubiquitous wireless communications? Smart users are solving this problem through the installation of a Distributed Antenna System, or DAS. These systems can be either a single carrier system tied to repeating the frequencies of a lone wireless provider, or they can be multi-carrier, or neutral host, systems that are capable of repeating multiple carrier’s frequencies.
DAS systems come in two varieties, passive and active. Passive systems are typically found in smaller buildings and are usually designed for a single carrier’s requirements. These systems consist of a donor antenna (or antennas) on the roof or exterior of the building to collect and return the carrier signal, a repeater or bi-directional amplifier (BDA) that amplifies the carrier’s licensed frequencies, and a coax cable system consisting of splitters, couplers, and antennas that spread the carrier signal throughout the covered space. These systems can be relatively inexpensive to design and deliver, but they must be approved by and registered with the individual carrier whose signals are being repeated. This is a key requirement for all DAS systems and is mandated by the FCC and the carriers who own the frequency license.
Contact us and our experts.
We are ready to review your technical needs and find a solution.
When passive DAS is not an appropriate system to use, an active DAS may be appropriate. These DAS systems are more robust and can cover much larger square footage buildings and campus environments. Active systems are also generally recommended for multi-carrier environments where two or more carriers are sharing a common coax and antenna design. Active systems are characterized by the use of a common head-end for the collection of carrier repeaters or BDA’s, or the installation of carrier base transmission stations (BTS), which are like mini-cell sites tied to the carrier network via high speed data circuits (DS1, DS3, Metro Ethernet, etc). The consolidated head-end equipment is then connected by fiber optic cable to various DAS nodes that are spread out in the building or campus. The coax connecting to the coverage antennas in the space are then connected to the DAS nodes or remotes. The same antennas used in an active DAS can also be used to carry public safety radio frequencies or WiFi signals throughout the space.
Installation of a properly designed and planned DAS inside a building or campus will have desired effect of improving the wireless capability of today’s smart devices, will improve battery life and performance of the devices, and will ensure that your users and customers enjoy the wireless service they have come to expect and demand.
Wycliffe Technologies and our DAS partners can help with the solution to your wireless coverage needs. From site engineering and surveys, system design, carrier approvals, equipment procurement, installation, testing and commissioning, to annual and ongoing maintenance plans, Wycliffe Technologies is your number one source for DAS.
